G4 MR11 LED replacement G4 MR11 LED



Magnum Ring















No Halogen G4

G4 MR11 LED Replacement



Specially designed to replace most "third degree burn" small hot G4 and MR11 halogen bulbs.





G4 MR11 Magnum RingTM

Part No.: 8001238

Ref. No.: G4-MR11-15W-D



Equivalent to an 18W incandescent beam.



Bright enough to read a book.



Ideal for cockpit, map reading lights, emergency lights, or any night illumination.


Not hot, warm to the touch.



All existing bulbs should be replaced with Dr. LED's bulbs to achieve all the benefits of superior LED technology.



For axial direction fixtures only.



Works with most MR11 fixtures.

G4 MR11 Drawing

Specifications:


Nominal Voltage:      11-15 VDC
Current Draw:     ~0.08A
Max. Diameter (mm): 38 mm (1.5")
Max. Height (mm):    28 mm (1.1")
Weight (g) :      ~50 g
Beam Angle:   Spot
Color:   Warm White (~3200 K)
Connection:   Bi-Pins







G4 fixture






G4 LED Cabin





G4 MR11 LED Replacement
